# Gas Material Balances and Straight Line Methods

1) Gas-in-place with water influx

In prior discussion of MBE, we multipled Gp  by Bg, the formation volume factor to obtain a reservoir volume in either cubic ft or bbls.  Remember the constant 0.02829 was used to calculate Bg in cubic ft, and 0.00504 for barrels.

Recovery of a dry gas with adequate production history and no water influx, can be determined by the P/Z verses Gp plot.    Overestimation of OGIP and ultimate recovery is possible in the case of a geopressured formation (green line) or water influx (purple line).

The pressure support from an aquifer may  not be apparent at first.  Assuming no water influx when one is present can result in over estimation of both gas in place and ultimate recovery.

In the plot above,  Pa is the abandonment pressure, with corresponding Za factor.   Frequently, the abandonment point is based more on economics, which may relate to the gas production from several fields.

From straight line MB methods,  we intend to calculate GIIP and cumulative water influx, We.  This is a function of aquifer’s geometry and transmissibility T = Kh.  Aquifers may initially provide complete support or partial support depending on these characteristics.

The next graph has purposely been left unlabeled.

This of course, is the straight line approach to material balance, and the correct model has the right cumulative water influx, We.  The points are labeled 1, 2 and 3, to show the time sequence. You can think of water influx as the opposite of production.

With Line (B), it appears that we will over estimate gas in place. Therefore, we must be using an We that is too high or too low? Think for a moment before proceeding.

Congratulations! We is too low. Just as the gas-in-place is too high when we neglect completely neglect water influx in the P/Z method, GIIP is overestimated when we underestimate it.

The straight line equation for gas reservoir with water influx is:

See Reference 1,  equation 10.77, on page 244.

The f(p ,t) term is the aquifer model, which can be  either steady-state or unsteady state.

The steady-state model means that the aquifer keeps up with production.  Perhaps initially, the field declines in pressure and rates drop off.  At this point, the total voidage in the reservoir equals the influx from the aquifer and the pressure stabilizes. In the steady state model, water influx rate (that is the derivative of We with time), is in proportion to the pressure drop.  Under this condition, the water influx rate must equal the gas and water rate, all expressed in reservoir units.

Example seen in Reference 4, page 277.  The example given is for an oil field, so the released free gas and oil production must be accounted included in the We calculation. Note the conclusion of the authors of reference 4, page 280: “In nearly all applications, the steady state models discussed in the previous section are not adequate in describing the water influx.”

Historically, the Hurst-van Everdingen (HE) model was used, and examples are provided in reference 1 (page 244),  reference 2, page 334, reference 3, page V-939, reference 4, page 281.   It is based on the same equation as the well test equation, the radial diffusivity equation.  Similar to the aquifer model are the diffusivity constant, which divides storage terms (porosity, total compressibility) by transmissibility (permeability/ viscosity). The HE model was later extended by Coats (1962) to include bottom water drive. Vertical permeability was added to the model.  Example is shown on page 300 of reference 4. I may add a discussion on this later.

Other models:

The Fetkovich model assumes pseudo-steady state conditions. It is easier to describe and implement than the HE model.  It will be described more fully in a separate section.  Carter Tracy is used in simulation and will be discussed separately. I have used it often in simulation. Many times, given a structure map, aquifers are part of the reservoir model using larger than normal grid cells. The same problem of identifying properties, particularly aquifer extent and permeability persists.

Geopressured Reservoir

Will add a link to this topic soon. Note that the geopressured reservoir appears at first to be an enormous field by conventional P/Z techniques.

Theoretical models of aquifers are the same for gas and oil bearing reservoirs, however oil reservoirs add complications due to gas evolution from oil.   The straight line methodology attempts to identify the GIIP and C (aquifer constant) that would explain the pressure decline in the field.  The alternative is history matching with reservoir simulation.   With increases in the speed of these programs,  the use of  MB straight line methods are in decline, at least in my experience.  The modern approach to simulation is to model flow up the wellbore and provide a complete forecast including well head pressures.

Avoid material balance methods when tank like assumptions will not hold. However, the MB method is far from dead.   The simplified model may help assist or give further support to a history match of a gas-aquifer system.   Interestingly, material balance methodology  is the preferred method for coalbed methane analysis for gas in place calculation.

References:

1. Lee, J.  and Wattenbarger, R.  Gas Reservoir Engineering, page 244-248

2. Dake, l. Fundementals of Reservoir Engineering, pages 29- 33, aquifer models 329- 340.

3. Holstein (Editor of Volume 5B), Petroleum Engineering and Petrophysics, pages 936 to 940.

4. Craft, Hawkins, and Peters, Applied Petroleum Reservoir Engineering, page 280.
